BURKERT TYPE 8652 - AirLINE - the valve island optimised for process automation

The valve island Type 8652 AirLINE has been especially developed for applications in process automation. New diagnostic functions can be visualised at the LC display, both in clear text as well as symbols. This makes it easy to relate to the shown messages and helps to save time during start-up and maintenance. Furthermore the diagnostic message is also available in the control. This therefore enables a fast overview of the plant status. The hardware is optimised for installation at the bottom of the control cabinet. Of course it is also possible to fix the AirLINE to top hat rail. Moreover, key pneumatic functions ensure increased process reliability. For instance, the non-return valves in the exhaust air ducts make sure there is no unplanned actuation due to pressure peaks.

• Compact design
• Easy diagnostics by LC display
• Process reliability through pneumatic functions
• Optimised for installation at the bottom of the control cabinet

Circuit functions

Circuit Function	Description
	Type: C, solenoid valve 2×3/2 way Servo-controlled, with manual override Normally closed
	Type: C, solenoid valve 2×3/2 way Servo-controlled Normally closed
	Type: D, solenoid valve 2×3/2 way Servo-controlled, with manual override Normally open
	Type: H, solenoid valve 5/2 way Servo-controlled, with manual override, with auxiliary pilot air Normally open
	Type: H, solenoid valve 5/2 way Servo-controlled Normally open
	Type: L, solenoid valve 5/3 way Centre position all connections locked, with manual override Normally closed
	Type: Z, solenoid valve 5/2 way Impulse version with 2 coils, with manual override Normally open

Type 8652 Can be combined with

	Type ME43 - Fieldbus gateway
	Type 2012 -  Pneumatically operated 2/2 way globe valve...
	Type 8695 - Control head for decentralised automation of...
	Type 8920 - Bürkert Communicator
	Type 8653 - AirLINE Field - the valve island optimised...
	Type 8614 - Pneumatic control cabinet solutions for...

*For selecting the correct product please refer to the technical data, images and notes for proper use according to the data sheet.
