Series XM
คุณสมบัติสินค้า:
SKU : Series XM
AIRTEC Series XM | double acting, stainless steel with adjustable cushions and magnetic piston for proximity sensors, diameter 32-125 mm
Share
หมวดหมู่ : Pneumatic , Piston rod cylinders , Brand , Airtec ,
แบรนด์ : AIRTEC
Share
คำอธิบาย | Technical details
AIRTEC Series XM | ISO 15552 double acting, stainless steel with adjustable cushions and magnetic piston for proximity sensors, diameter 32-125 mm
| Operating pressure | 1 ... 10 bar |
| Temperature range | -20°C ... +80°C ( 0 ... +150°C for high temperature version) |
| Max. stroke | 1000 mm |
| Medium | Filtered, oil-free and dried compressed air according to ISO 8573-1:2010, Class 7:2:4, instrument air, free of aggressive additives. Alternatively the pressure dew point must be at least 10°C below lowest occurring ambient temperature. |
| Materials | Cylinder tube : AISI 304 (1.4301) or AISI 316 (1.4401) End caps : AISI 304 (1.4301) or AISI 316 (1.4401) Piston rod : AISI 304 (1.4301) or AISI 316 (1.4401) Seals : PU, NBR, PBT, PTFE |
 | Cylinders in accordance with 2014/34/EU (ATEX) available. (Chapter 13) |
*Pneumatically operated spool valve. The valve switches upon pressurization of the pilot port.
Data Sheets
